Lithium Ion Battery Cabinet 83L (Single Door)

This 83L Single Door Lithium Ion Battery Storage Cabinet is designed for safe, smart Li-Ion battery charging, featuring a smart cooling system, double steel walls, four adjustable shelves with 20 plug sockets, and advanced safety features compliant with FM6050, OSHA, and NFPA standards.

Add to enquiry

DESCRIPTION

Product Overview:

The 83L Single Door Lithium Ion Battery Smart Charging Cabinet is specifically engineered for the safe charging of Li-Ion batteries. Packed with smart features to keep batteries cool and provide early detection if a faulty battery catches fire, this cabinet offers a secure and efficient charging solution for demanding environments.

Key Features:

Double Steel Walls: Constructed with double steel walls featuring a 40mm gap for enhanced insulation and fireproof protection.

Smart Cooling & Safety:

  • Adjustable Exhaust Fan: Helps dissipate warm air to maintain optimal battery temperature.
  • Temperature & Humidity Monitoring: Sensors are easily visible from the outside for real-time environmental tracking.
  • Smoke Detector: Provides highly sensitive early warning in case of battery failure or fire.

Intelligent Power Management: The external isolation switches allow you to disconnect power to the cabinet or specific plug boxes without opening the doors.
Efficient Charging Layout: With four adjustable shelves, each shelf features a plug box with 5 lightning-protected sockets, totaling 20 sockets for versatile connectivity.
Additional Safety & Convenience: The internal light automatically activates when the door is opened.
Adjustable Shelving with Perforations: Enhances air circulation.
Spill Tray: Captures leaks and spills to ensure a safe charging environment.

Warranty:

  • Cabinet body: 10 years
  • Lock, parts, and accessories: 1 year

Brand: pH7

Minimum Order Quantity (MOQ): 1

Unit Of Measure (UOM): Each

In Stock

Last Updated: 1st September 2025 at 2:11pm New Zealand Standard Time (NZST)

Disclaimer: Inventory levels shown are for informational purposes only and may not reflect current stock.
Please contact us directly to confirm exact availability.

Volume83 Litres
CertificationCE
Door TypeSingle door/manual
ColourCabinet: Black
Door: Blue
External Dimensions (HxWxD/cm)189x60x46
Packing Dimensions (HxWxD/cm)203x67x55.5
Number of Sockets (Standard PDU industrial sockets)32 total sockets (AC220V/50Hz total)
Adjustable Shelves4
Shelf Loading Weight (kg)75
Operating VoltageAC 220V/50Hz
